5 TACTIX 1-10×24

To change your battery, unscrew the outer cap on the illumination/parallax knob, then replace it with a CR2032 battery. The illumination knob has 6 stops with off switches in between.

Place the rifle solidly on a rest and remove the bolt. Sight through the bore at a target approximately 25 yards away. Move the rifle and the rest until the target is visually centered inside the barrel. With the target centered in the bore, make windage and elevati8on adjustments until the reticle crosshair is also centered over the target. (If a laser bore sighting or any other similar device inside the bore was used, it must be removed before firing. An obstructed bore can cause serious damage to the gun and possible injury to the shooter.)

You can use other mounts and rings for Riton Riflescopes, but we suggest using the high-quality rings and mounts that can be found on ritonoptics.com. Make sure you get rings or a mount that matches the diameter of your riflescope.

We suggest always using the torque information from your rings to ensure the best fit without damage to your scope. Riton products require torqueing of 15-18in/lbs for rings and mounts.

To change the height or location of your throw lever loosen the two screws located in the middle of the throw lever or blank. Slide the blank of throw lever in or out of the reverse dove tail slot. Tighten the two screws to no more than 3in lbs. They only need to be snug to stay in, do not over tighten.

Before contacting Riton make sure that you’ve done some troubleshooting. Most problems that are thought to be associated with your riflescope are actually mount problems. Make sure your mount is the right size and that the screws aren’t torqued too hard on the mount.

Our Warranty is Simple:

• Riton Optics Lifetime warranty will cover all variable rifle scopes (non-electro-optics) and accessories, the 2-year warranty will cover electro-optics.
• The Riton Optics warranties will cover all owners regardless of original purchaser.
• Contact Riton Optics to obtain a Return Merchandise Authorization (RMA) number. Please email us at info@ritonoptics.com or call us 855-397-4866. Products returned without acquiring a Riton Optics RMA number will not be processed.
• All warranty replacements will receive a brand-new product off the shelf or be offered a product of equal or lesser value as a replacement. We will not ever replace the product with a repaired or refurbished product.
• Communication regarding product repairability or replacement will be communicated within two business days of receiving and approving of return.

Learn more about our Limited Lifetime Warranty.

Check out Riton University for in depth videos about our optics.

If you have questions regarding this product, please submit them to info@ritonoptics.com or call us at 855-397-4866. We appreciate customer feedback and will get back to you as soon as possible.
